'�NOTE:This draft dated 15 April 2006' by DasH - Page 179 of 460

FED-STD-791D

storage precautions, emergency treatment and measures, and spill practices of each chemical are

explained.

5.2 Dry cleaning solvent (CID A-A-59601D).

5.3 Carbon remover (Penetone Corporation 74 Hudson Avenue, Tenafly, New Jersey,

Penetone ECS or equivalent) [u,u,u].

5.4 n-Heptane [1,3,0].

5.5 Acetone [1,3,0].

5.6 SAE J1966, lubricating oil.

5.7 Polytetrafluoroethylene tape and gasket material [0,0,0].

5.8 Fiberfrax insulation [0,0,0].

5.9 Raxbestos-Manhattan A-56 gasket material [0,0,0].

5.10 Metal specimens [0,0,0].

Aluminum

ASTM B 209

8Mn Annealed, 110ksi (758 MPa)

yield strength-UNS R56080

Titanium

99.9% purity

Silver

AMS 5040

Steel

SAE AMS 5518

Stainless Steel

5.11 Glass wool fiber, Corning Cat. No. 3950 [0,0,0].

5.12 400 grit silicon carbide paper [0,0,0].

5.13 30 grit aluminum oxide [0,0,0].

6. PROCEDURE

6.1 Cleaning procedure.

6.1.1 Test-oil sump. The test-oil sump assembly is completely dismantled for cleaning

of all internal components after each test. The sump interior is thoroughly cleaned with a

suitable solvent, hand scrubbing, or mild abrasive blast to remove all traces of deposits from the

previous test. A new test-oil pumpshaft seal is installed prior to each test.

178
