FED-STD-791D

Crinkled carbon

-----

Same as for smooth carbon, ridged or uneven surface, not

smooth

Less than 1/64 in thickness

Light

1/64 to 3/64 in thickness

Medium

3/64 in thickness or more

Heavy

Same as for smooth carbon, blistered, bubbled

Blistered

-----

Less than 1/64 in thickness

Light

carbon

1/64 to 3/64 in thickness

Medium

3/64 in thickness or more

Heavy

-----

Same as for smooth carbon, flaked or broken blisters,

peeling

Flaked carbon

Light

Less than 1/64 in thickness

Medium

1/64 to 3/64 in thickness

3/64 in thickness or more

Heavy

1 Some difficulty may be encountered in distinguishing between light smooth carbon deposit

and heavy varnish. The varnish deposit appears shiny and glossy and upon scraping

indicates a tacky consistency or thin, brittle flaking. The smooth carbon deposit appears

dull and lusterless and upon scraping reveals a grainy consistency.

Heater-mount front.

Heater-mount rear.

Seal plate.

Test bearing.

6.7.1.5 The specific areas rated on each of the six major items are as follows:

a. End cover: The surface of the end cover normally exposed to test oil.

b. Spacer and nut: The entire surface of the spacer, nut, lock-washer, and flat washer (all

considered to be one piece) normally exposed to test oil.

c. Heater-mount front: The surface of the heater-mount front which is parallel to the plane

of the end cover and normally exposed to test oil. The portion of the heater-mount front

which contacts the heater-mount retainer is not included in the area rated.

d. Heater-mount rear: The surface of the heater-mount rear which is parallel to the plane

of the end cover and normally exposed to test oil.

e. Seal plate: The visible surface of the seal plate, with the slinger in place, normally

exposed to test oil.

f. Test bearing: The test bearing is divided into four section for rating purposes. These

four sections are in turn broken down into eleven specific areas as follows:

1. Front

Rollers

2. Rear

189
